MÀNG UMF CỦA MITSUBISHI

Item		Unit	Specification
Element Model Number		－	UMF-824WI	UMF-2024WFA	UMF-2012WFA
Photograph		－
Nominal membrane surface Area		m2	8	20
Dimensions	Width	Ø	110	170
	Height	mm	830	810
Material	Housing	－	PVC	ABS
	Element water collecting header	－
	Cap	－
	Sealant	－	Polyurethane
Nominal pore size		µm	0.1		0.03
Membrane type		ー	MF		UF
Performance	Filtration flow rate	m3/h	0.4	1.0	0.6
	Maximum operating pressure	kPa	≦196　(≦2kg/cm2)
	Operating temp.	℃	≦45

*Product specifications described herein are subject to change without notice.
*Dimensions and weights herein are approximate and exclusively for information purpose

Capsule type

Item	Unit	Specification
Product name	–	20M0060A	20M1500A	20M3400A
Photograph	–
Length of module	ｍｍ	200	630	774
Maximum exteral diameter	mm	48	114	165
Membrane Surface Area	m2	0.6	15	34
Material of housing	–	Polycarbonate
Material of cap	–	Polycarbonate	Polypropylene
Sealant	–	Sealant
Maximum operating pressure	MPa	≦0.3
Maximum operating temperature range	℃	1-40
Housing joint size	–	Screw
Connection	–	G1/4	PT3/4-PT1/2	25A
Drawing(PDF)	–	20M0060A	20M1500A	20M3400A

*Product specifications described herein are subject to change without notice.

3000 Series (PE) Module Specifications

Capsule type

Item		Unit	Specification
Model number			30M0007HP	30M0030JP
Photograph
Membrane	Material		Polyethylene
	Pore size	µm	0.1 (nominal)
	Maximum TMP	MPa	0.1	0.2
Mambrane surface area		m2	0.07	0.3
housing	Material		Polycarbonate
	Length	mm	98	123
	Maximum Outer Diameter	mm	32	69
	Connection		PT1/4	PT1/4
	Sealant		Polyurethane
	Maximum Pressure Capacity	MPa	0.1	0.49
Operating Temperature Range		℃	≦45	≦40
Initial Water Flow Rate(25℃)		NL/min at 0.01MPa	42	140
Drawing(PDF)			30M0007HP	30M0030JP

※Product specifications described herein are subject to change without notice.

TERAPORE^®4000 Series (PE) Module Specifications

Capsule type

		Unit	Specification
Product name			40M0007HP	40M0030JP	40M0090Q
Photograph
Applications			Water filtration
Pore size		µm	0.1
Membrane Surface Area		m2	0.07	0.3	0.9
Material	Hollow Fiber		Polyethylene
	Housing		Polycarbonate
	Sealant		Polyurethane
Outer Dimensions	Length	mm	98	123	192
	Maximum Outer Diameter	mm	32	69
Connection			R1/4(PT1/4)		R1/2(PT1/2)
Maximum Pressure Capacity		MPa	0.1	0.49	0.3
Operating Temperature Range		℃	5-45
Initial Water Flow Rate (25℃)		L/min at 0.03 MPa	1.0	4.0	8.0
Drawing			40M0007HP	40M0030JP	40M0090Q

Cartridge (10 inch)

Item		Unit	Specification
Model number			40E0240KP	40E0180KX
Photograph
Type			O-ring222	Gasket
Membrane	Material		Polyethylene
	Pore size	µm	0.1
	Maximum Pressure Capacity	MPa	0.2
Membrane Surface Area		m2	2.4	1.8
Filter	Material		Polycarbonate
	Length	mm	258	249
	Outer Diameter	mm	70
	Sealant		Polyurethane
	Connection		SOE-O-ring222	DOE-Gasket
Operation temperature range		℃	≦45
Initial water flow rate		L/min	37	32
Designed standard flow rate	Tap water	L/min	7	6
	Other pure water	L/min	25	25

STERAPORE^®2000 Series (MHF) Module Specifications

Capsule type

Item	Unit	Specification
Product name	–	20M0060A	20M1500A	20M3400A
Photograph	–
Length of module	ｍｍ	200	630	774
Maximum exteral diameter	mm	48	114	165
Membrane Surface Area	m2	0.6	15	34
Material of housing	–	Polycarbonate
Material of cap	–	Polycarbonate	Polypropylene
Sealant	–	Sealant
Maximum operating pressure	MPa	≦0.3
Maximum operating temperature range	℃	1-40
Housing joint size	–	Screw
Connection	–	G1/4	PT3/4-PT1/2	25A
Drawing(PDF)	–	20M0060A	20M1500A	20M3400A

*Product specifications described herein are subject to change without notice.
